Model | JD-2600D |
Measurement Range | |
Sphere | 0 ~ ±25 D,0.01/0.12/0.25 D step |
Cylinder | 0 ~ ±9.99 D,0.01/0.12/0.25 D step |
Axis | 0 ~ 180° (1° step) |
Add. | 0 ~ +9.99 D,0.01/0.12/0.25 D step |
Prism degree | 0 ~ 15 D,0.01/0.12/0.25 D step |
Measurement Mode | |
Cylinder | +, -, ± |
Prism | X_Y, P-B |
Contact lens | soft/hard lens |
Measuring mode | single lens/progressive lens/contact lens (automatic recognition) |
Specifications | |
Diameter of lens | Φ20 ~ Φ108 mm |
PD | 45 ~ 90 mm, 0.5 mm steps |
Speed of measurement | 0.1 s |
Light source | LED Green Source |
Wavelength | 545 nm |
ABBE Value | 30 ~ 60, no need to set |
Display | 7" TFT LCD Tilting Touch Screen |
UV | Y |
Data communication | RS232 serial port |
Printer | Thermal Printer |
Dimension | 222 × 161 × 372 mm |
Package | 470 × 360 × 620 mm |
Weight | 7kg |
Power supply | AC 100 ~ 240 V, 50/60 Hz |
This type auto lensometer with 7" touch screen, can be measured SPH, CYL, AXIS, ADD, PD, UV, it also has printing function. It can basically meet the regular needs of users.
JD-2600A is an auto lensometer with good comprehensive performance, which can measure SPH, CYL, AXIS, ADD, Prism, PD, PH, UV. Its data communication form is RS232 serial port.
Although the configuration of JD-2600D is slightly lower than JD-2600A, as a basic model, it can basically meet daily measurement needs. Apart from minor differences in appearance, screen quality, and machine material, the JD-2600D does not provide a Pupil Height (PH) measurement compared to the JD-2600A in terms of functionality.
D-910 is a fully upgraded version of JD-2600A. The basic measurement function and measurable lens types of JD-2600A are supported by the D-910. At the same time, the D-910 has better performance, better display screen, higher measurement accuracy, and more optional data communication methods.
Screen quality and machine material: JD-2600D<JD-2600A<D-910
SKU | Display | Measurement | Data communication |
JD-2600D | 7" 20-85°adjustable LCD touch display screen | SPH, CYL, AXIS, ADD, Prism, PD, UV | RS232 serial port |
JD-2600A | 7" 20-85°adjustable LCD touch display screen | SPH, CYL, AXIS, ADD, Prism, PD, UV, PH | RS232 serial port |
D-910 | 7" 40-90°adjustable New capacitive touch screen with high resolution | SPH, CYL, AXIS, ADD, Prism, PD, UV, PH, Lens Diameter and PCL | RS232 serial port Bluetooth USB WIFI |
You can choose according to your needs.
Processing time
According your order list. we will supply delivery time .
Commonly is 5-7 work days after we confirm payment
Shipping time
By Express : 3-7 days . Door to door service
By Air : 3-7 days . (the goods arrival at your local air ports )
By sea : 30-40 days (the goods arrival at your local sea ports )
PS : by air or by sea, if you need door to door service, please tell us . we will help you checking the extra door to door cost.
one year
For ensuring all the items are in good quality, we will test all products before the packages were sent out. Once the machine have some question, please don't worry. kindly send us some images of the situation , Video and machine series, and explain the question in where . we will supply solution to you deal soon.
If in Warranty, some spare parts broken in the Use. kindly supply picture or video , and machine series number .
We will send the spare parts by express to you soon.. and we bear express cost .
